Hybrid HDVR Video Recorder 4+2CH AI PROGRESS - VIXVR04IB
THIS PRODUCT IS SHIPPED ONLY TO ITALY
For the price of this product (if not listed) and a possible order, ask a quote. For multiple products, create a single list with the respective quantities. You'll receive the quote by email within 24 hours
Categories:
Security policy
We use the SSL standard to ensure security during payment
Delivery policy
Orders made on workdays, until 08:00 are shipped same day (if all goods are in stock)
Return policy
Purchases can be returned within 14 days (as per terms and conditions of sale)
Hybrid Video Recorder “PROGRESS” 4BNC+IP (6CH) 4K AHD+CVI+TVI+CVBS+IP
CHANNEL EXAMPLES:
4 BNC + 2 IP
1 BNC + 5 IP
2 BNC + 4 IP
• Out bandwidth 48Mbps
• Audio 4 in/1 out
• Alarm 4 in/1 out
• 1 Lan Port
• 1 BNC / 1HDMI 4K / 1VGA FHD
INTELLIGENT VIDEO ANALYSIS
MAX 4 BNC CHANNELS
• Perimeter intrusion detection
• Line crossing detection
• People and vehicle detection
TECHNICAL CHARACTERISTICS
Inputs 12Mbps~36Mbps
Outputs 48Mbps
Analog video input 4CH inputs
IP video input 4 channels (IP only up to 6 channels)
Composite video input up to 6 channels (analog video + IP video)
Audio Compression: G.711a, Video: H.264/H.265
Screen Resolution
Analog: 8MP(15fps), 5MP(20fps), 4MP/3MP/1080P/
720P/960H (30fps)
IP: 8MP/4MP/3MP/1080P/720P
Speed
Analog: 8MP:10fps (each channel); 5MP: 14fps (each channel);
4MP: 18fps (each channel); 1080P: PAL: 25fps (each channel)/NTSC:
30fps (each channel)
IP: PAL: 25fps (each channel)/NTSC: 30fps (each channel)
MD Event (Sensitivity Level 1~8); Video loss; Beep,
Email, Mobile APP push notification
Playback function Fast forward/backward (2x, 4x, 8x,16x);
Slow forward (1/2x, 1/4x, 1/8x, 1/16x)
Playback
8MP: 28fps
5MP: 48ps
4MP: 60fps
1080P: 120fps
AI
Perimeter intrusion detection, line crossing detection,
people and vehicle detection
MAXIMUM 4 CHANNELS
BNC 1 (704*576)
VGA 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080)
HDMI 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080,
2560*1440, 3840*2160/EDID）
Ethernet 1 RJ45 100/1000 Base-T
USB USB2.0 * 1 (front); USB2.0 * 1 (rear)
Audio 4 in/1 out
E-sata /
HDD 1 SATA HDD, up to 10TB
LAN 1
RS485 1
Alarm in/out 4 in/1 out
Dimensions (WxDxH) 300 X 220 X 53 mm
Input voltage/current 12V DC/ 2A
Power consumption (excluding HDD) 4.7W
Operating temperature/humidity Temperature: -10°C~+50°C
Humidity: Less than 90%RH
