Hybrid HDVR Video Recorder 16+8CH AI PROGRESS - VIXVR16IB
THIS PRODUCT IS SHIPPED ONLY TO ITALY
For the price of this product (if not listed) and a possible order, ask a quote. For multiple products, create a single list with the respective quantities. You'll receive the quote by email within 24 hours
Categories:
Security policy
We use the SSL standard to ensure security during payment
Delivery policy
Orders made on workdays, until 08:00 are shipped same day (if all goods are in stock)
Return policy
Purchases can be returned within 14 days (as per terms and conditions of sale)
Hybrid Video Recorder “PROGRESS” 16BNC+IP(24CH) 4K AHD+CVI+TVI+CVBS+IP, 2HDD-2LAN
Technical Specifications
Channel examples: 4 BNC + 20 IP / 10 BNC + 14 IP
Protocols: AHD + CVI + TVI + CVBS + IP
Bandwidth: IN: 64~192 Mbps - Each BNC disabled = + 8 Mbps
(see datasheet for explanations) - OUT: max. 192 Mbps
Recording: IP: max. 8MP (max 8Mbps) - BNC: 4K (10FPS), 5MP (15FPS), 2MP (25FPS), C
Local playback: (max 16ch) 8MP: 160FPS, 5MP: 240FPS, 2MP: 480FPS
CVBS output: 1 (704*576) - Default disabled
Monitor output: HDMI 1 (max. 4K), VGA (max. Full HD)
HD slot: 2 x SATA up to 10TB
Network interface: 2 LAN x RJ45 - 10/100/1000Mbps
Audio inputs/outputs: 16 IN / 1 OUT
Alarm inputs/outputs: 16 IN / 1 OUT
Intelligent Video Analytics - BNC: MAX 8 BNC CHANNELS (Only if CVBS output is disabled) - Facial recognition - Detection: Faces, Perimeter Intrusions, Line Crossing, People & Vehicles
Power Supply: 12V DC / 5A / ≤20W
Operating Temperature: 0°C ~ +50°C
